iOKE868 Smart Metering Kit with wM-Bus

iOKE868 Smart Metering Kit with wM-Bus

iOKE868 Smart Metering Kit with wireless M-Bus

The iOKE868 Smart Metering Kit with wireless M-Bus offers reliable, low-power communication for energy monitoring. Compatible with most modern smart meters (IEC62056-21 and SML messages), the optical unit is magnetically attached to the meter to read and transmit data at user-defined intervals. A 10-year replaceable battery, external antenna, and intuitive configuration tool ensure flexibility, long life, and easy setup, delivering detailed energy insights.
iOKE868 Smart Metering Kit with wM-Bus
wireless M-Bus Logo

Key Features

  • OMS Compliant (EN 13757-4)
  • Dual colored status LED, push button
  • Flexible configuration via PC-tool

Advantages

  • Battery life: ~ 10 years
  • Battery can be replaced
  • Online visualization of power consumption
  • Easy to use local USB interface of iO891A
  • Adjustable transmission interval

Kit Content

  • iO891A optical interface head
  • 868 MHz antenna with 2 m cable and MMCX connector
  • USB cable 1.8 m (male A to male Micro B)
  • The optical unit can be magnetically attached to the smart meter to read data via the infrared interface, extract the required values, and transmit them securely over the wM-Bus network. This enables accurate, real-time, and historical energy consumption analysis for improved monitoring and management.

    With its intuitive configuration tool, users can easily adjust radio, calendar, and filter settings at any time. These features provide greater visibility into energy usage and promote more efficient resource management.

    The iO891A optical reader head is designed for precise and reliable smart metering applications. Equipped with a u.fl antenna connector, it delivers outstanding wireless performance even in challenging RF environments.

    The high-capacity integrated battery ensures up to 10 years of operation under standard configurations (15-minute transmission interval), making it ideal for long-term, maintenance-free deployments.

  • >> Scroll table horizontally

    Frequency range868 MHz
    TechnologywM-Bus OMS compliant (EN 13757-4)
    Max. output power+14 dBm
    Dimensions47 x 34 x 35 mm
    Operating temperature+5 °C to +55 °C
    InterfacesMicro USB connector for power supply, configuration and direct USB mode
    AntennaExternal antenna (MMCX connector)
    Battery life~ 10 years; can be replaced
